CHENLONG – GH-4250 – Semi-Automatic Horizontal Band Saw Machine
Specifications
| Make | CHENLONG |
|---|---|
| Model | GH-4250 |
Description
CHENLONG – GH-4250 – Semi-Automatic Horizontal Band Saw Machine
1. Horizontal Metal Cutting Band Saw Machine Is A Semi-Automatic Band Sawing Machine.
2. Specially Suitable For Sawing Profiles.
3. Maximum Cutting Size Of 500×500mm
Specifications
| Product Name | Horizontal Metal Cutting Band Saw Machine | |
| Brand | CHENLONG | |
| Model | GH4250 | |
| Maximum Cutting Size (Round) | 500mm | |
| Maximum Cutting Size (Quadrate) | 500×500mm | |
| Blade Line Speed | 40/55/70/90 m/min | |
| Blade Size | 41×1.3×5700 mm | |
| Blade Guides | Carbide And Bearing Blade Guides | |
| Blade Cleaning | Wire Brush & Flood Coolant | |
| Blade Tension | Manual | |
| Motors | Main Motor | 5.5kw |
| Hydraulic Motor | 0.75kw | |
| Water pump Motor | 120w | |
| Work Vise Control | Hydraulic | |
| Machine Size(L×W×H)mm | 2850×1200×1850 | |
| Standard Equipment: | ||
| 1. Blade Cleaning Brush. | ||
| 2. Working Light. | ||
| 3. Power Roller Table 1pc (1m) | ||
| 4. One Piece Of Bi-metal Saw Blade. | ||
| 5. One Set Of Tools With Tool Box | ||
| Optional Equipment: | ||
| 1. Extra Common Roller Table | ||
| 2. Automatic Chip Conveyor | ||
| 3. Inverter | ||
| 4. Laser Projector | ||
| 5. Hydraulic Blade Tension | ||
